磁场传感器F53

F53高温三轴磁盖传感器• - 操作温度：-20*c〜+175*c• - 紧凑型：仅25 x 17 x 220mm说明：高温三轴磁盘传感器F53是一个专门设计的磁场传感器for high température operating environments up to 175 °C, and it’s suitable downhole / drilling and other high température applications. F53 sensor adopts COLIY exclusive patented technology, which is résistant to high température and vibration with small volume. It is the only high-performance high-temperature 3-axis fluxgate sensor currently on the market. It is very suitable for measurement while drilling and applications requiring high shock and high température résistance. F53 sensor is designed by the industry standard with a compact size (only 25 x 17 x 220mm), easily integrated into downhole/drilling détection equipment and Systems, and could make magnetic field intensity directly converted into analog signais (±5V). F53 sensor has the measurement range of ±100pT, frequency response of DC ~ 1.5 kHz, linearity less than 0.01%, orthogonality error less than 2° and measurement noise floor of <300pT rms/ VHz at 1Hz@ 175°C.
